The EX Series amps are Stetsom's best-sellers. They are excellent with bass as well as with voice.



TECHNICAL SPECS (1 Ohm):

• Number of Channels: 1
• RMS Power at 1 Ohm 14.4V: 1850W RMS
• RMS Power at 2 Ohm 14.4V: 985W RMS
• Supply Voltage: 9.5 ~ 15V
• Frequency Response: 10Hz ~25KHz
• Crossover Low Pass: 50Hz ~25KHz
• Crossover High Pass: 10Hz ~700Hz
• EQ - BASS @ 45Hz: ±10dB
• EQ - MID BASS @ 270 Hz: ±10dB
• EQ - MID HIGH @ 2KHz: ±10dB
• Over Clip (Power): 15%
• Signal to Noise: > 90 dB
• Harmonic Distortion: ≤ 10% THD
• Input Sensitivity: 0.2V
• Input Impedance: 19K OHMS
• Min. Output Impedance: 1 OHM
• Consumption with Musical Signal: 1.3A ~80A
• Consumption with Bass Signal: 1.3A ~160A
• Dimensions (H x W x D): 75 x 310 x 170 mm / 3 x 12.2 x 6.7 inches
• Weight: 2.0 Kg / 4.4 lbs



TECHNICAL SPECS (2 Ohms):

• Number of Channels: 1
• RMS Power at 2 Ohm 14.4V: 1820W RMS
• RMS Power at 4 Ohm 14.4V: 1100W RMS
• Supply Voltage: 9.5 ~ 15V
• Frequency Response: 10Hz ~25KHz
• Crossover Low Pass: 50Hz ~25KHz
• Crossover High Pass: 10Hz ~700Hz
• EQ - BASS @ 45Hz: ±10dB
• EQ - MID BASS @ 270 Hz: ±10dB
• EQ - MID HIGH @ 2KHz: ±10dB
• Over Clip (Power): 15%
• Signal to Noise: > 90 dB
• Harmonic Distortion: ≤ 10% THD
• Input Sensitivity: 0.2V
• Input Impedance: 26K OHMS
• Min. Output Impedance: 2 OHMS
• Consumption with Musical Signal: 1.6A ~75A
• Consumption with Bass Signal: 1.6A ~150A
• Dimensions (H x W x D): 75 x 310 x 170 mm / 3 x 12.2 x 6.7 inches
• Weight: 2.0 Kg / 4.4 lbs

Download Manual
