The Iron Line Series amps feature the most compact and enhanced design in the market, while offering high fidelity sound in bass, mid and highs.



TECHNICAL SPECS:

• Number of Channels: 1
• RMS Power at 2 Ohm 13.8V: 400W RMS
• RMS Power at 4 Ohm 13.8V: 160W RMS
• RMS Power at 2 Ohm 14.4V: 430W RMS
• RMS Power at 4 Ohm 14.4V: 250W RMS
• Supply Voltage: 9 ~ 15V
• Frequency Response (-3dB): 10Hz ~ 22 KHz
• Crossover Low Pass: 60Hz ~ 22KHz
• Crossover High Pass: 10Hz ~ 700Hz
• Signal to Noise: > 90 dB
• Harmonic Distortion: > 0,01% THD
• Input Sensitivity: RCA 200mV / Wire 1.5V
• Input Impedance: RCA 38K Ohms / Wire 10K Ohms
• Consumption with Musical Signal: 18A
• Consumption with Bass Signal: 36A
• Dimensions (H x W x D): 52.5 x 99.8 x 127.5 mm
• Weight: 508g

Download Manual
