Stetsom EX 1200 EQ Mono Digital Amplifier Full Range Class D 1.2k RMS (DISCONTINUED)
The EX Series amps are Stetsom's best-sellers. They are excellent with bass as well as with voice.
TECHNICAL SPECS (1 Ohm):
- Number of Channels: 1
- RMS Power at 1 Ohm 14.4V: 1560W RMS
- RMS Power at 2 Ohm 14.4V: 970W RMS
- Min. Output Impedance: 1 Ohm
- Input Impedance: 26K Ohms
- Input Sensitivity: 0.2V
- T.H.D: ≤ 10% THD
- Signal to Noise Ratio: >90dB
- Freq. Resp. (-3dB) @ 1 Ohm: 10Hz ~ 25KHz
- Crossover Low Pass: 50Hz ~ 25KHz
- Crossover High Pass: 10Hz ~ 700Hz
- EQ - BASS @ 45Hz: ±10dB
- EQ - MID BASS @ 270 Hz: ±10dB
- EQ - MID HIGH @ 2KHz: ±10dB
- Over Clip (Power): +15%
- Power Supply: 9.5 ~ 15Vdc
- Consumption Music: 1 ~ 57A
- Consumption BASS: 1 ~ 115A
- Dimensions (H x W x L): 64 x 260 x 170 mm / 2.5 x 10.2 x 6.7 inches
- Weight: 1.7 Kg / 3.8 lbs
TECHNICAL SPECS (2 Ohms):
- Number of Channels: 1
- RMS Power at 2 Ohm 14.4V: 1410W RMS
- RMS Power at 4 Ohm 14.4V: 860W RMS
- Min. Output Impedance: 2 Ohms
- Input Impedance: 25K Ohms
- Input Sensitivity: 0.2V
- T.H.D: ≤ 10% THD
- Signal to Noise Ratio: >90dB
- Freq. Resp. (-3dB) @ 1 Ohm: 10Hz ~ 25KHz
- Crossover Low Pass: 50Hz ~ 25KHz
- Crossover High Pass: 10Hz ~ 700Hz
- EQ - BASS @ 45Hz: ±10dB
- EQ - MID BASS @ 270 Hz: ±10dB
- EQ - MID HIGH @ 2KHz: ±10dB
- Over Clip (Power): +15%
- Power Supply: 9.5 ~ 15Vdc
- Consumption Music: 1 ~ 56A
- Consumption BASS: 1 ~ 112A
- Dimensions (H x W x L): 64 x 260 x 170 mm / 2.5 x 10.2 x 6.7 inches
- Weight: 1.7 Kg / 3.8 lbs
