The DIGITAL BASS line was developed for automotive sound lovers looking for maximum performance at low frequencies.

Its  5Hz to 250Hz frequência frequency response delivers quality and definition of lower frequencies, delivering powerful and intense bass.



TECHNICAL SPECS (1 Ohm):

• Number of Channels: 1
• RMS Power at 1 Ohm 12.6V 3100W
• RMS Power at 2 Ohm 12.6V 2000W
• RMS Power at 1 Ohm 14.4V 3950W
• RMS Power at 2 Ohm 14.4V 2600W
• Supply Voltage: 9V ~ 16V
• Frequency Response (-3dB): 5Hz ~ 250Hz
• Crossover Low Pass: 35Hz ~ 250Hz
• Crossover High Pass: 5Hz ~ 35Hz (Subsonic)
• Bass boost: 0 ~ +18dB (Fixed 35Hz)
• Signal to Noise: >90 dB
• Input Sensitivity: 200mV
• Input Impedance: 20K Ohms
• Musical Consumption @ 12.6V: 169A
• BASS Consumption @ 12.6V: 338A
• Dimensions (H x W x L): 3.07" x 9.11" x 10.8"
• Weight: 6.6lbs / 3.1kg



TECHNICAL SPECS (2 Ohms):

• Number of Channels: 1
• RMS Power at 2 Ohm 12.6V 3000W
• RMS Power at 4 Ohm 12.6V 2000W
• RMS Power at 2 Ohm 14.4V 3700W
• RMS Power at 4 Ohm 14.4V 2350W
• Supply Voltage: 9V ~ 16V
• Frequency Response (-3dB): 5Hz ~ 250Hz
• Crossover Low Pass: 35Hz ~ 250Hz
• Crossover High Pass: 5Hz ~ 35Hz (Subsonic)
• Bass boost: 0 ~ +18dB (Fixed 35Hz)
• Signal to Noise: >90 dB
• Input Sensitivity: 200mV
• Input Impedance: 20K Ohms
• Musical Consumption @ 12.6V: 147A
• BASS Consumption @ 12.6V: 295A
• Dimensions (H x W x L): 3.07" x 9.11" x 10.8"
• Weight: 6.6lbs / 3.1kg
